24FT HVLS Industrial Ceiling Fan 208-240V 3Ph - Energy Efficient Large Area Air Circulation for Fan Warehouses & Factories, 24FT3PH

Model 24FT3PH Certifications cULus,CE,SAA Fan Diameter 24FT Number of Blades 5 Cooling Coverage 16146ft² Voltage 220V ±10% 3Ph(L1, L2, L3, G) Full Load Current 4.9 A Fan Watts 1.5KW RPM Range 10-54 RPM Air Flow@Max Speed 549,144 CFM Drive Motor Permanent Magnet Synchronous Motor Speed Variable Speed Drive Type Direct Blade Material Al-Mg Fan Weight 273LBS Noise Level ＜40dB Protection Level(Motor) IP55 Standard Includes I-Beam Structure Mounting Kits; 59" Extension Tube; Control Cabinet; 131Wire Conduit; 131'Wire Rope; 164' UL Listed Wire. Packing Size Box A:34.6"x31.5"x20.9" Box B:135.4"x13.4"x10.6" Gross Weight Box A: 356 LBS Box B: 178 LBS WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s)  for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
