3-Point PTO Stump Grinder & 48'' PTO Flail Mower Bundle, SG24&EFS48
Sale price
$1,304.10
Regular price $2,898.00
Skip to product information
3-Point PTO Stump Grinder
Flywheel Diameter
24 in
Mounting
3 Point Hitch Cat. 1 (Quick Attach Compatible)
Flywheel Thickness
3/4 in
PTO Input
540 RPM
Carbid Tip
34 PCS
Max. Torque
1200 N·m
Carbid Tip Material
YG11C
PTO Shaft Weight
44 LBS
Tip Holder Material
42CrMo
Dimensions
29 × 37 × 38 in
PTO HP Required
15–45 HP
Packing
Iron Frame + Carton
PTO Shaft (Included Shipping)
1-3/8” 6 Spline Tractor and Implement Ends PTO Driveline Shaft with Slip Clutch
Weight (N.W/G.W.)
450/563 LBS
Friction Torque Limiter (Slip Clutch)
Included
48'' PTO Flail Mower
Engine Power Required
15-35HP
Blade Speed
142 ft/s
Working Width
48in
Drive Type
Belt drive
Overall Width
56in
Number Of Belts
3
Blade Ground Clearance
0.6in-1.8in
Belt Size
V Belt 13X1041
Max. Cutting Diameter
Depends On The Type Of Grass
Drive Belt Tensioner
yes
Number Of Blades
20
Deck Material
0.16in
Blade Type
Hammer
Side Plate Material
0.24in
Size Of Blades
3.5 X 3 X 1.6in
PTO Shaft RPM
540 RPM
Blade Weight
0.8lbs
Driveline Shaft Length
T5-LF-31 with shear bolt ；31in- 43in
Blade （Tines）Material
Cast Steel
Spline End
1.375in z6
Rotor Bearing
SKF bearing
Gearbox Oil Type
85W-90
Rotor Diameter
3in
Dimensions (L x W x H)
57 X 30 X 28in
Rotor Swing Diameter
11in
Finish
Powder Coating
Rotor Thickness
0.3in
Warranty
1 year
Rotor Shaft Speed
2958 rpm
Weight (N.W./G.W.)
379/470 lbs
WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s) for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
