3-Point PTO Stump Grinder & Wood Chipper Bundle; SG24PRO; BX42S; Orange
Sale price
$1,439.10
Regular price $3,198.00
Skip to product information
PTO Stump Grinder
Flywheel Diameter
24 in
Friction Torque Limiter (Slip Clutch)
Included
Flywheel Thickness
3/4 in
Mounting
3 Point Hitch Cat. 1 (Quick Attach Compatible)
Carbid Tip
34 PCS
PTO Input
540 RPM
Carbid Tip Material
YG11C
Max. Torque
1200 N·m
Tip Holder Material
42CrMo
PTO Shaft Weight
44 LBS
PTO HP Required
15–45 HP
Dimensions
29 × 37 × 38 in
PTO Shaft (Included Shipping)
1-3/8” 6 Spline Tractor and Implement Ends PTO Driveline Shaft with Slip Clutch
Packing
Iron Frame + Carton
(P-P)
34-43.3 in
Weight (N.W/G.W.)
450/563 lbs
PTO Wood Chipper
Tractor Power
18-45HP
PTO Shaft RPM
540 RPM
Max. Throughput Capacity
4 in
Flywheel Speed
540 RPM
Infeed Opening
4*10 in
Drive Type
PTO
lnfeed Chute Opening
20*20 in
Driveline Shaft Length
T5-LF-31 in with shear bolt, 31.5-43 in
Feeding Opening
Gravity Feed
Spline End
1 3/8"Z6
Discharge Chute Rotation
360 Degrees
3-Point Hitch
CAT 1
Rotor Diameter
25 in
Dimensions (L x Wx H)
38x 33x 43 in
Rotor Thickness
0.5 in
Finsh
Powder Coat Paint Galvanized Steel
Rotor Weight
82 lbs
Warranty
1 year
Number Of Blades
4+1
Net Weight
397 lbs
Blade Weight
0.9 lbs
Gross Weight
441 lbs
Blade (Tines) Material
4CrW2Si
WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s) for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
