HONDA GX690 22HP 688cc Twin Cylinder Gasoline Engine Powered 7" Hydraulic Feeding Wood Chipper, DCH7
Sale price
$3,779.55
Regular price $8,399.00
Skip to product information
Engine
HONDA GX690
Blade
2 x Blades; 1 x Anvil
Engine Type
Air Cooled 4-Stroke OHV Petrol Engine，90° V-Twin Design, Horizontal Shaft
Blade Material
A8 （5Cr8MoVSi）
Displacement
688 cc; 22 HP
Blades Type
Double Edge Blade
Rated Power
13.0 kw / 3600 RPM
Flywheel System
Open Top Flywheel 26 in x 1 in Twin
Max. Net Torque
48.3 N·m / 2500 RPM
Discharge Chute
360 Degree Rotating
Fuel Capacity
3.17 gal
Emergency Stop
Stop Bar
Recommended Oil
SAE 10W-30 Classification SE or Higher
Towing Length
Tow Bar With 2 in Coupler
Hydraulic Tank
6.87 gal
Wheel
5.3-12 Tubeless
Starting
Electric Starting
Wheelbase
52.5 in
Battery
36Ah 12V Lead-Acid Battery
Axle
Damping Torsion Axle
Ignition System
CDI
Max. Speed
50 mph
Governor System
Mechanical Centrifugal Type
Chassis
Channel Steel Welded Frame
Belt
2 x V-Belts
Package Method
Iron Fram With Black Film
Belts Material
Kevlar
Weight (N.W./G.W.)
1389 / 1587 lbs
Clutch
Centrifugal Clutch
Product Size (L*W*H)
137 x 55 x 90 in
Cutting Method
Disc
Packing Size (L*W*H)
87 x 46 x 51 in
Max. Chipping Dia.
7 in
Machine Warranty
2 Years
Feed Roller
7.5 in x 6.5 in
Engine Warranty
2 Years
WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s) for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
