42 in Rotary Tiller, 3 Point Hitch Cat.1, Chain Drive, PTO Shaft Included with Shear Bolt, 15–35 HP, LRT42

42 in Rotary Tiller, 3 Point Hitch Cat.1, Chain Drive, PTO Shaft Included with Shear Bolt, 15–35 HP, LRT42

$719.55 $1,599.00
Skip to product information
42 in Rotary Tiller, 3 Point Hitch Cat.1, Chain Drive, PTO Shaft Included with Shear Bolt, 15–35 HP, LRT42
  • 42 in Rotary Tiller, 3 Point Hitch Cat.1, Chain Drive, PTO Shaft Included with Shear Bolt, 15–35 HP, LRT42
  • 42 in Rotary Tiller, 3 Point Hitch Cat.1, Chain Drive, PTO Shaft Included with Shear Bolt, 15–35 HP, LRT42
42 in Rotary Tiller, 3 Point Hitch Cat.1, Chain Drive, PTO Shaft Included with Shear Bolt, 15–35 HP, LRT42

42 in Rotary Tiller, 3 Point Hitch Cat.1, Chain Drive, PTO Shaft Included with Shear Bolt, 15–35 HP, LRT42

$719.55 $1,599.00
Working Width 42 in Number of Flanges 5 Overall Dimensions (L×W×H) 50.6 x 30.6 x 32 in Number of Blades 20 Max Working Depth 5 in Blade Arrangement 4 Blades per Flange Offset Capability 4 in Left / Right from Center Blade Type Heat-Treated 60Si2Mn Steel “C”-Shaped Skid Shoes Adjustable Depth Control PTO Shaft Included Yes Rotor Bearing NSK Bearing PTO Shaft Series 4 PTO Shaft with Shear Bolt, 1-3/8" × 6-Spline (Both Ends), Length: 27.5-30 in Rotor Rotation Forward Tractor PTO Speed 540 RPM Rotor Speed @ 540 PTO RPM 284 RPM Recommended PTO HP 15-35 HP Rotor Diameter 2.5 in 3 Point Hitch Cat.1 Rotor Swing Diameter 13.8 in Quick Hitch Compatibility Cat.1 Quick Hitch Compatible Side Drive Type Chain Driven Rear Deflector Hinged Side Box Lubrication SAE 80W-90, Approx. 1 L (1.06 qt) NOTE: SHIPPED WITHOUT OIL. Parking Stand Included Yes Main Gearbox Cast Iron Oil-Bath Gearbox, Gear Ratio 1.46:1 Packing Size (L×W×H) 52 x 24 x 26 in Gearbox Lubrication SAE 80W-90, Approx. 0.5L (0.53 qt) NOTE: SHIPPED WITHOUT OIL. Weight (N.W/G.W.) 309/380 lbs WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s)  for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
